16
16
3.3 Replacing the Power Supply Unit
1. Refer to section 3.1 to remove the electronics cover.
2. Disconnect 2 connectors and remove 2 screws on the power supply unit.
3. Replace the power supply unit.
4 . Reassemble the parts in the reverse procedures.
Screws
