TSC TTP-346M - Multi-interface Board Description

8
8
TTP-2410M/346M/644M
TTP-246M Plus/344M Plus
Bar Code Printe
r
Service Manual
Multi-interface board
Connector Description Remark
1
Main board connector
2
SD card slot
3
Ethernet RJ-45 connector
4
PS/2 connector
1
3
2
4
