TTP-2410M/346M/644M
TTP-246M Plus/344M Plus
Bar Code Printe
r
Service Manua
l
GPIO with multi-interface board
Connector
Description
Remark
1
GPIO connector
2
Main board connector
3
SD card slot
4
Ethernet RJ-45 connector
5
PS/2 connector
6
GPIO power connector
2
1
4
3
5
6
10
12
Table of Contents
Default Chapter
2
Table of Contents
2
1 Fundamental of the System
3
Overview
3
2 Electronics
7
Summary of Board Connectors
7
Interface Pin Configuration
12
3 Mechanism
15
Remove Covers and the Lower Front Panel
15
Replacing the LCD Panel Module
17
Replacing the Power Supply Unit
18
Replacing Multi-Interface Board
19
Replacing the Main Board
20
Replacing the Platen Roller Assembly
21
Replacing the Stepping Motor
22
Replacing the Print Head ASS'Y
23
Replacing the Gap/Black Mark Sensor Module
25
Replacing the Media Damper
26
Replacing the Ribbon Rewind Spindle
27
Cutter Module Installation (Option)
28
Peel-Off Kit Installation (Option)
29
Internal Rewinding Kit Installation (Option)
33
4 Troubleshooting
37
Common Problems
37
Mechanism Fine Adjustment to Avoid Ribbon Wrinkles
42
5 Maintenance
44
Update History
46
