TSC TTP-368MT Series - 3.2 Loading the Ribbon

- 17 -
3.2 Loading the Ribbon
3.2.1 Loading the Ribbon
1. Lift the handle to open the printer right
side cover.
2. Install the ribbon and paper core onto
the ribbon supply spindle and ribbon
rewind spindle.
3. Push the print head release lever to
open the print head mechanism.
