- 22 -
6. Adjust the front label guide to fit the width of the label.
7. Making sure the label is into both label guides.
Left label guide
Right label guide (Adjustable)
8. Close the print head mechanism. Make sure
the latches are engaged securely.
9. Using the front display panel, set media
sensor type and calibrate the selected sensor.
Note:
* Please calibrate the gap/black mark
sensor when changing media.
* Please refer to video on TSC YouTube or
driver CD.
Loading path for media
Front label
guide
