Document No: LT0117 F4000 LCD Operator's Manual

Placing Into Operation

Issue 2.38 19 April 2002 Page 9-5

9.4.2 POWER SUPPLY

A) Number of Power Supplies Fitted (1 to 3).................................…...............

B) - If more than 1, Configuration Master/Slave/Slave OK..............................

C) Mains Wired correctly, Cover secured.....................………………………..

D) "Mains Isolate Switch" and "Mains Earth" labels fitted...……………………

E) Mains Earth wired correctly and securely fitted..........………………………

F) AC Fuse F1; Fitted and Rated at 5.0 A....................………………………..

G) +VBF Fuse F2; Fitted and Rated at 1.6 A..................………………………

H) Bells Fuse F3; Fitted and Rated at 1.6 A.................………………………..

I) +VNBF Fuse F4; Fitted and Rated at 1.6 A.................……………………..

J) Mains Voltage Level - 240 VAC +6% -10%............……………… VAC

K) Charger Voltage at Batt + (27.25 - 27.35 VDC).....………………. VDC

L) Quiescent Panel Current (FROM BATTERY)............…………… A

M) Panel ALARM current (TWO ZONES, FROM BATTERY).....….. A

N) Battery Fitted - Type..................... : Rating AH

O) Battery Test Resistors Removed (NZ Panels Only)..........…………………

9.4.3 MAIN BOARD

A) Fitted correctly and securely on standoffs...............…………………………

B) Main PSU Loom fitted correctly...........................……………………………

C) PSU Monitor FRC Loom fitted correctly....................………………………..

D) Display Board FRC Loom fitted correctly..................………………………..

E) LCD/Keyboard FRC Looms fitted correctly..................……………………..

F) MCP wires fitted to J18 (MCP)............................……………………………

G) Microswitch wires fitted to J40 (Inner Door).............………………………..

H) If fitted, Outer Door switch wired to J41................…………………………..

I) Earth wires fitted correctly (2 off).....................………………………………
