F4000 LCD Operator's Manual Document No: LT0117
Operating Instructions - System Functions
Page 6-4 19 April 2002 Issue 2.38
6.2 BELL TEST
6.2.1 FUNCTION
To operate the Bell Output for a period of five (5) seconds.
6.2.2 OPERATING SEQUENCE
From any information display or base display press:
Note: For a networked panel after pressing SYSTEM a prompt will be given requesting
whether the local panel or a remote panel should be tested. For the remote panel
option a further prompt will be given for the SID of the remote panel. Enter the SID of
the remote panel to be tested.
Bell test can also be started by the TEST SYSTEM BELLS command sequence:
- The LCD briefly displays "Bells Test Started".
- The Bell Output is turned on for 5 seconds.
6.2.3 NOTES
(a) The Local Bell output will be turned on and the BEL token in the output logic will be
TRUE for the 5 second "BELL TEST", even if the BELLS are ISOLATED, or
externally silenced (New Zealand mode).
