F4000 LCD Operator's Manual Document No: LT0117
Operating Instructions - System Functions
Page 6-12 19 April 2002 Issue 2.38
NOTES (CONTINUED)
Responders - On a per Responder Basis
PRly - Responder has opened its Power Relay.
Scan - FIP is not receiving data from this responder.
Forgn - Responder is unconfigured, or more than one of same address.
TypeM - Type mismatch between actual responder type and the type stored in
the FIP database, or a SS database is being sent to an MPR that
cannot process it correctly.
Brk1 - No messages received by Responder on Channel 1.
Brk2 - No messages received by Responder on Channel 2.
RyBd - Relay Board fault.
L2F - AAR or MPR fault e.g. Top Board Fault, Power Line 2 Fault, or device
type mismatch.
RZDUs - On a per RZDU Basis
Forgn - Reply received from an unconfigured RZDU.
BatLo - Battery low at RZDU.
DispF - Display fault at RZDU.
BatFl - Battery fail at RZDU.
Scan - FIP is not receiving data from this RZDU.
StstF - RZDU failed its self test.
ChgrF - Charger fault at RZDU.
Network Panels Page 0
ScanF - The Local Panel is not receiving any data from the Remote panel
indicated.
LnkIA - The Local Panel is not receiving channel A test data from the Remote
panel indicated.
LnkIB - The Local Panel is not receiving channel B test data from the Remote
panel indicated.
SysFlt - The Remote Panel has a system fault.
NetFlt - The Remote Panel has a network fault.
Stdby - The Remote Panel has a standby condition.
Network Panels Page 1
Abnml - The Remote Panel has an Abnormal status present.
BellI - The Remote Panel's bells are isolated.
TEvac - The Remote Panel is asserting Trial Evacuation.
SilAlm - The Remote Panel is asserting Silence Alarms (Silence Bells)
BrigT - The Remote Panel is asserting Brigade Test.
SysFRcl - The Remote Panel has information that should be recalled on its own
LCD display using the System Fault recall command.
Network Panels Page 2
CmnPtI - A point on this FIP is isolated.
TstFlI - The FIP is signalling a test fail condition.
SysTst - The remote panel is currently executing a system test.
