um DSR EX 125 User Manual

INSPECTION TYPE 2
NOTA
Engine/trans.
Cycle
General
SPARK PLUG: Change
EXHAUST SYSTEM: Check the correct tightness of the bolts and clamps
ENGINE SUPPORT BOLTS: Check nominal torque tightness
SECONDARY TRANSMISSION: Check the condition of the chain, sprocket and
plate - Renew if they have reached the end of their useful life
AIR FILTER: Renew
BRAKE CALLIPERS: Check nominal torque tightness
SWINGING ARM SHAFT: Check for absence of play and nominal torque tightness
WHEELS: Check bearing play and the nominal torque tightness of the shaft
STEERING SHAFT: Check for absence of play – Adjust if necessary
PROP STAND AND/OR CENTRE STAND: Grease
FINAL CHECK: Carry out an on road test drive, paying attention to the general
operation of the brakes, steering, clutch, suspensions, engine, lights and instru-
ment panel lights
SYSTEM
Note 2
Note 1
INSPECCIÓN TIPO 3
NOTE
Engine/trans.
Cycle
General
RADIATOR: Check external appearance – Clean if necessary
FRONT SUSPENSION: Change fork oil
MILOMETER TAKE-OFF: Grease
FINAL CHECK: Carry out an on-road test drive, paying attention to the general
operation of the brakes, steering, clutch, suspensions, engines, lights and instru-
ment panel indicator lights.
SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SERVICE NO. KM
1
ST
SERVICE
RUNNING IN
INSPECTION
TYPE 1
INSPECTION
TYPE 2
INSPECTION
TYPE 3
VALVE
PLAY
1000
6000
12000
18000
24000
30000
36000
42000
48000
54000
60000
66000
72000
78000
84000
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
26
REGULAR INSPECTION
AND ADJUSTMENTS
WORKSHOP MANUAL
