Fit:
- The gear selector lever (9) and the spring, using the
bolt (10).
Fit:
- The gear change selector shaft (11).
N.B.:
FIT THE GEAR CHANGE SELECTOR SHAFT, BY ALIGNING
THE ENDS OF THE RETURN SPRING WITH THE POSITIO-
NING BRACKET (12) ON THE CRANKCASE.
N.B.:
THE INTERMEDIATE GEAR REMOVED IN DISMANTLING
MUST BE REFITTED.
10
11
9
12
60
ASSEMBLING THE ENGINE
AND ADJUSTMENTS
WORKSHOP MANUAL
