short pulse, large variance of before and after signals.
● Blackman：The best range resolution, the worst frequency resolution, it can be used to measure the single
frequency signal, to find higher harmonics.
(2) Set Vertical Unit
Vertical units can be Vrms or dBVrms. Press F4 to select the desired unit. Vrms and dBVrms show the vertical
amplitude by means of logarithmic and linear. To display the FFT spectrum in a larger dynamic range, dBVrms can
be used.
5.3 Logic Operations
Press MATH button, then press F1 to select logic operations to enter the Logic menu.
Logic Operations Menu
Functions Options Descriptions
Type Logic
Operator
AND Source 1 AND Source 2
OR Source 1 OR Source 2
NOT Source 1 NOT Source 2
XOR Source 1 XOR Source 2
Source 1
CH1, CH2, CH3,
CH4
Set any one of the CH1~CH4 for logic as source 1
Source 2
CH1, CH2, CH3,
CH4
Set any one of the CH1~CH4 for logic as source 2
Reverse Open, Close Reverse logic waveform
During operation, when the source channel voltage value is greater than the corresponding channel trigger value,
the logic decision will be 1, otherwise it is 0. Waveform transform will be in binary operation. Four logical operations
examples are shown in the table below.
Four logical operations
S1 S2 AND OR XOR
S1 NOT
0 0 0 0 0 0 1
0 1 0 1 1 1 0
1 0 0 1 1
1 1 1 1 0
