Chapter 8 Automatic Measurement
UPO2000CS series digital fluorescence oscilloscope can automatically measure up to 34 parameters. Press the
MEASURE button to enter the automatic measurement menu.
Automatic Measurement Menu
Functions Options Descriptions
Signal
Source
CH1, CH2, CH3,
CH4
Select data source from any one of the CH1~CH4
All
Parameters
Off Close all Parameters
On Pop-up window with all parameters is displayed
User Defined
On/Off
Open/Close menu for user defined paraters. When it is on,
define all parameters required with the Multipurpose knob. It
can customize and display up to 5 parameters at the same
time.
Measurement
Statistical
Analysis
Off Turn off feature
Peak
Automatic calculation of user defined parameters of average,
max, and min. Only applicable when user defined parameters
are present.
Difference
Automatic calculation of user defined parameters of average,
difference, and number of measurements. Only applicable
when user defined parameters are present.
Next Page
Go onto the next page
Automatic Measurement Menu (2)
Functions Options Descriptions
Signal
Source
CH1, CH2, CH3,
CH4
Select data source from any one of the CH1~CH4
Indicator
Selection
Using the Multipurpose knob, up to 34 parameters can be
selected.
Indicator
Off Close parameter indicator
On Open parameter indicator
Clear Clear all parameters
Return Return to automatic measure main menu
