UNI-T UPO2000CS Series

UPO2000CS series User Manua
75
11.1 Waveform Recording
Press UTILITY then press F5 to enter auxiliary function settings menu (2). Press F1 to enter the wave recording
menu.
Waveform Recording Menu
Functions Options Descriptions
Record
Close Close Record Function
Settings Enter Record Settings Menu
Operation Enter Record Operation Menu
Press F1 to select recording operation, and set parameters for waveform recording.
Record Settings Menu
Functions Options Descriptions
Record Settings Set Record Parameters
Record
Length
100ns~10s Set waveform record interval between each frame
End
Frame
1~65000 Set the frame where recording automatically ends
Playback
Delay
10ms~1s Set the delay between each frame set when playing
Largest
Frame
65000
Shows the maximum number of frames which can be
recorded (will change according to current storage depth)
After setting up the recording parameters, the recording operation can be performed by pressing F1.
Record Operation Menu
Functions Options Descriptions
Record Operation Carry out record, playback, and stop operation.
Playback Playback the recorded waveform
Stop Stop recording or playback waveform
Record Start recording waveform
11.2 Pass Test
The pass (fail) test is by using a template to detect whether the input signal satisfies the template requirements.
