Trend Technology (Chengdu) Ltd
completing the “data transmission” or “transmission interface” task, select “Document”
“print preview” to preview the waveform or interface (as the case may be) before printing.
The preview waveform is the last screen of waveform data uploade
d from the oscilloscope to
the communication and control software after “data transmission” is completed, or the
waveform on the computer hard disk or mobile USB device which is downloaded to the
software with the “load” function.
umber of channels working at the time of data transmission, you can select
the channel mode on the waveform preview interface with the selection function of the menu.
When uploading with two channels, you can select “single channel” (CH1, CH2), “two
ls” (CH1 & CH2, CH1 & Math, CH2 & Math) or “all” to preview the waveform. To quit
the preview screen, click the exit button.
The preview interface is the last screen uploaded by the oscilloscope to the computer after the
When “data transmission” is complete, select “Document”
“Print” to print the waveform or
The printed waveform is the last screen of waveform data uploaded from the oscilloscope to the
control software after “data transmission” is completed, or the waveform on
the computer hard disk or mobile USB device which is downloaded to the software with the
The print interface is the last screen uploaded by the osci
lloscope to the computer after the
“transmission interface” is closed.
After the “data transmission” or “transmission interface” task is complete, select “Document”
“exit” to quit the oscilloscope communication and control software.
menus under the FUNCTION menu can be operated only when the “data transmission” or “transmission
interface” task is complete.
Mathematics functions : When this menu is clicked, a mathematics function dialog box will pop up to enable
“mathematics selection” or “FFT mathematics”, as shown in Fig 2
