Unify OpenScape Cordless IP V2 Service Documentation

Planning a OpenScape Cordless IP System
c03.fm
Installing Base Stations
A31003-C1020-S100-03-7620, 12/2017
50 OpenScape Cordless IP V2, Service Documentation
3.5 Installing Base Stations
3.5.1 Ethernet Connection Cable
First Steps:
1. Pull up the upper part of the housing and fold it forwards 1
2. Insert a plug from an Ethernet cable into the LAN connection socket at the top
of the device 2
3. Insert the second Ethernet cable plug into a LAN socket for your local network
or on the router 3
4. Close the flap
Mounting the Antennas:
Devices that are intended to be used as base station should be equipped with the
external antennas supplied.
