c03.fm
Planning a OpenScape Cordless IP System
Installing Base Stations
A31003-C1020-S100-03-7620, 12/2017
OpenScape Cordless IP V2, Service Documentation 55
3.5.5 Tools/Aids
The tools and aids listed below will be required when carrying out the activities
described in the following sections. However, they are not included in the delivery
scope.
3.5.6 Outdoors
NOTE: The base station contains an overvoltage protector.
• Features of the outdoor housing
– No special grounding necessary.
The outdoor housing is made of 100% plastic.
– Ethernet cable entry.
– Base station protection at ambient temperature between -20°C and
+50°C (can be operated without heating).
• Figure 16 shows the components of the outdoor housing.
– The outdoor housing is supplied pre-installed.
– The necessary installation material is supplied loose.
– Install the outdoor housing on a mast or on masonry/wood/brick walls.
– Connect the cable from the communication system (see Section 3.5.4.2).
Table 7 Tools/aids
Designation Application
Crosstip screwdriver size 3 To attach installation plate, sun shield
Crosstip screwdriver size 2 To attach mast blocks/mast installation of outdoor
housing
Triangle head screwdriver M 6 To attach and close the housing/outdoors
Aids
Masonry drill, 8 mm diameter To drill holes for wall installation, housing/outdoors
Masonry drill, 5 mm diameter To drill holes for wall installation, housing/indoors
