3.5.4 Indoors
3.5.4.1 Wall Mounting
The base station must be freely accessible.
NOTE: When installing a DECT IP base station, the antennas should face
downward.
– Two wall anchors with 5 mm diameter, two screws with 3.5 mm diameter.
1. Drill four holes (8 mm diameter) in the wall where the base station is to be
mounted. For dimensions, see Figure 18. Insert the wall anchors in the holes.
2. Screw in the screws through the outdoor housing into the openings of the wall
anchors and tighten the screws. Different mounting material may be needed
depending on the composition of the mounting wall, for example, wood
screws for wooden walls.
3. Connect the base station connection cable(s).
4. Secure the housing cover with the four screws.
– Antenna position Antennas pointing towards open space,
in direction of radio area
– DECT IP Base station mounting
position
vertical/180
°
rotated
– Mounting Mounting material not included in scope of
supply
