Unify OpenScape Cordless IP V2 Service Documentation

Planning a OpenScape Cordless IP System
c03.fm
Installing Base Stations
A31003-C1020-S100-03-7620, 12/2017
54 OpenScape Cordless IP V2, Service Documentation
3.5.4.2 Ethernet Socket Allocation in the DECT IP Base Station
PIN Signal MDI Signal MDI-X
1 Tx+ (V+) Rx+ (V-)
2 Tx- (V+) Rx- (V-)
3 Rx+ (V-) Tx+ (V+)
4V+V+
5V+V+
6 Rx- (V-) Tx- (V+)
7V-V-
8V-V-
Table 6 pin assignment of the Ethernet socket
