Diagnosis and Maintenance
c07.fm
Testing the Radio Area
A31003-C1020-S100-03-7620, 12/2017
94 OpenScape Cordless IP V2, Service Documentation
Figure 4 Outdoors - Base station installation site/radio area
Bldg
B
concrete/
mounting
height
25 m
Scale 1:1000
BS
Bldg
E
concrete/
27 m
high
Bldg F
concrete/10 m high
Bldg
C
concrete/
27 m
high
Minimum supply range
Property line
Bldg
G
Hall
steel/
10 m
high
Bldg A
brick/15 m high
