P31003C1020M1000276A9, 01/2018
OpenScape Cordless IP V2, Administrator Documentation 99
LDAP directory – configuration example
Access to the LDAP server
14 LDAP directory – configuration example
To allow the entries of an LDAP directory to be displayed on the handsets, you will need to configure the phone’s
LDAP client. This involves the following:
• Setting up access to the LDAP server and database
• Specifying the attributes to be displayed ( p. 101)
• Defining search criteria (filters) ( p. 101).
14.1 Access to the LDAP server
To ensure that entries from the LDAP database are displayed on the phones, enter the access data via the web
configurator.
Settings Online directories Corporate
Click on next to the name of the LDAP directory you want to edit . . . the LDAP configuration page is
opened.
Enter a name for the directory in the Directory name field.
This is the name under which the directory will appear in the list of network directorys on the telephones (
p. 105).
Select the option Enable directory, so that the directory will be displayed on the telephones.
Enter the access data for the LDAP server
LDAP Search base (BaseDN)
The LDAP Search base (BaseDN) parameter specifies the starting point for the search in the LDAP directory tree.
This starting point must be defined on the LDAP server and entered here for the LDAP client according to the
Server address IP address or domain name of the LDAP server, e.g. 10.25.62.35 or ldap.exam-
ple.com
Server port Port on which the LDAP server expects queries from the clients. Normally the port
number 389 is used (default).
Username / Password Credentials for access to the LDAP server.
It is also possible to use individual access data for each handset ( p. 52).
ldap.ourserver.com
cn=user_1,ou=users,dc=com-
************
cn=phonebook,dc=exam-
Our Directory
