Unilumin UpadIV2 User Manual

Chapter 1 Product Introduction
3
1.3 Specification
Parameter
UpadIV2
UpadIV2.9
Physical
Parameter
Pixel configuration
1R1G1B
1R1G1B
LED type
3-in-1 Black SMD
3-in-1 Black SMD
Pixel density(dots)
147,456
112,896
Pixels per panel(dots)
192x192
168x168
Cabinet size(WxHxD)/(mm)
500x500x70.1
500x500x70.1
Display area(m
2
)
0.25
0.25
Material
Die-cast Magnesium
Die-cast Magnesium
Planeness(mm)
＜0.25
＜0.25
Weight(kg)
6.3
6.3
Electronic
parameter
Grey scale(bit)
14
13
Refresh rate(Hz)
3,840
2,880
Drive type
1/16
1/28
Frame frequency(Hz)
50/60
50/60
Data interconnection
Signal cable≤100m; Multi-mode fiber≤300m;
Single-mode fiber≤10km
Optical
parameter
Brightness(nits)
1000
800
Color temperature(K)
2,000~9,300 adjustable
2,000~9,300 adjustable
Contrast ratio
3,000:1
3,000:1
Viewing Angle(°)
140/120
140/120
Electrical
parameter
Input voltage(V)
AC 100~240
AC 100~240
Input frequency(Hz)
50~60
50~60
Input power
<max/typical>(W/panel)
120/40
120/40
Circumstance
parameter
Storage temperature and humidity(℃/RH)
-20~+50/10~80%
-20~+50/10~80%
Operation temperature and
humidity(℃/RH)
-10~+45/10~80%
-10~+45/10~80%
Ingress protection
IP30
IP30
Note: Specifications are for reference only and are subject to change without notice.
