Chapter 2 Installation and Wiring
12
2.3 Wiring for LED Display
2.3.1 Common Cables
Common cables used for the indoor series LED displays include:
Incoming Power Cable
Power Cable Passing
Through Cabinet
Incoming Signal Cable
Signal Cable Passing
Through Cabinet
DVI Cable
USB Cable
