Chapter 2 Installation and Wiring
10
2.2.2 Installation of Hanged LED Display
1) Adjust the levelness of the hanging beam by using the synthetic fibre slings, to
prevent tilting of the LED display, as shown in Figure 2-9.
Figure 2-2 Installation of Hanged Cabinets (1)
2) Fasten the cabinets sequentially from middle to both sides. These cabinets can be
fastened through upper/lower locks to the hanging beam and can be fastened with
each other through the left/right locks, as shown in Figure 2-10.
Figure 2-3 Installation of Hanged Cabinets (2)
To Next Page
