into place. Route the LED wires to the control module.
H9. 4 PIN ORANGE CONNECTOR 2 STAGE SHOCK SENSOR, ZONE-4, (Under door
on main unit)
H-6: 20 PIN WIRE CONNECTORS:
H6/1 BROWN/BLACK WIRE: 200 mA(-)Ground Output When Running.
This wire provides a negative output during the remote start process. It can be used to
operate by-pass modules that may be required in your installation. This wire will provide
ground once the remote start process has been initiated and will remain grounded while
the engine is running.
H6/2 GRAY/BLACK WIRE: 200 mA(-)Second Starter Output.
This line can be used if a second starter line is needed. Some vehicles require a
two-starter line to remote start. This wire provides a negative output that will work the
same way as the Violet starter line in connector H1.
1 11
2 12
3 13
4 14
5 15
6 16
7 17
8 18
9 19
10 20
Pin Color Function
1 Brown/Black
Ground Output While Running
2 Gray/Black Second Starter Output
3 Pink 2-Step Unlock/Factory Disarm/Sensor
By-pass
4 White/Blue Instant Start And Turn Off Input
5 White Dome Light Control Output
6 Brown/White Horn Output (Programmable)
7 Black/Green Channel 4 Programmable Output
8 Black/White Neutral Safety Switch Input
9 Orange/White Ground Output When Disarmed
10 White/Red Tachometer Signal Input
Pin Color Function
11 Blue/Black Accessory 2 Control Output
12 White/Green Diesel Wait To Start Input
13 Yellow Ignition 3 Control Output
14 Green Zone 3(-)Negative Door Pin Trigger
15 Gray Channel 3(Trunk) Output
16 Blue Zone 2 Negative Hood/Trunk Trigger
17 White/Violet (+) Brake Switch Shutdown Input
18 Violet Zone 3 (+) Positive Door Pin Trigger
19 White/Black (-)Negative Hood Pin Safely
Shutdown
20 Orange Ground Output When Armed
To Next Page
