Climate Control Zoning System II installation and operation manual | Chapter 4 – Installing thermostats and sensors l 19
Finishing installation
1. Ensure the thermostats are working correctly.
Turn thermostat setpoints to maximum to obtain a heating
demand and make sure the actuators are running.
2. Set the thermostats to the dened operating settings.
3. Close the base unit cover.
4. Attach the thermostats to the wall.
5. Print out and complete in the "Installation report"
located at the end of this manual.
6. Give the manual and all system information to the user.
1
3
5
6
1
2
4
Figure 4-13: Finishing installation
