Uponor Climate Control Zoning System II User Manual

38 | uponorpro.com
Dimensions
Base unit and antenna
9.7" (245 mm)
2.2"
(55 mm)
10.1" (257 mm)
4.3" (110 mm)
3.1" (80 mm)
5.5" (140 mm)
4.3" (110 mm)
Base unit with expansion module and antenna
4.3" (110 mm)
3.1" (80 mm
)
5.5" (140 mm)
9.7" (245 mm) 5.5" (140 mm)
4.3" (110 mm) 4.3" (110 mm)
2.2"
(55 mm)
15.6" (397 mm)
Thermostats
A8500167
3.1" (80 mm)
2.4" (60 mm)
3.1" (80 mm)
1"
(26,5 mm)
3.1" (80 mm)
2.4" (60 mm)
3.1" (80 mm)
1"
(26,5 mm)
A8500165
Figure A-4: Base unit and antenna dimensions
Figure A-5: Base unit with expansion module and antenna dimensions
Figure A-6: Thermostat dimensions
