Uponor Smatrix Base

Contents
Uponor Smatrix Base components ...............................4
System example ................................................................4
Safety instructions .......................................................5
Controller ..........................................................................5
Thermostat/System device ...............................................5
Quick Guide ...................................................................7
Installation ........................................................................7
Register thermostat and/or system device to a controller .9
Unregister one channel or system device ........................10
Unregister all channels ....................................................10
Communications protocol................................................10
Miscellaneous functions ..................................................10
Technical data .............................................................11
Uponor Smatrix Base
components
An Uponor Smatrix Base system may be a combination
of the following components:
• Uponor Smatrix Base Controller X-145 (controller)
• Uponor Smatrix Base Timer I-143 (timer I-143)
• Uponor Smatrix Base Thermostat D+RH T-149
(digital thermostat T-149)
• Uponor Smatrix Base Thermostat Prog.+RH T-148
(digital thermostat T-148)
• Uponor Smatrix Base Thermostat Dig T-146 (digital
thermostat T-146)
• Uponor Smatrix Base Thermostat Standard T-145
(standard thermostat T-145)
• Uponor Smatrix Base Thermostat Flush T-144 (fl ush
thermostat T-144)
• Uponor Smatrix Base Thermostat Public T-143
(public thermostat T-143)
• Uponor Smatrix Base Slave Module M-140 (slave
module M-140)
• Uponor Smatrix Base Star Module M-141 (star
module M-141)
• Uponor Smatrix Transformer A-1XX (transformer
A-1XX)
System example
NOTE!
This is a quick start guide to serve as a
reminder for experienced installers. We
strongly recommend reading the full manual
before installing the control system. See QR-
code for download link.
03 | 2015
Uponor Smatrix
Base
UK INSTALLATION AND OPERATION
MANUAL
03 | 2015
Uponor Smatrix
Base
UK INSTALLATION AND OPERATION
MANUAL
03 | 2015
Uponor Smatrix
Base
UK INSTALLATION AND OPERATION
MANUAL
https://www.uponor.co.uk/smatrix/downloads.aspx
