52 l Smatrix Pulse | Installation and Operation Manual
Relay Module
Part number A3801263 Relay Module (M-263)
IP IP20, Class II (IP: degree of inaccessibility to active parts of the
product and degree of water)
Maximum ambient RH (relative humidity) 85% at 68°F (20°C)
ERP IV
Low voltage tests EN 60730-1* and EN 60730-2-1**
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum
matters) tests
EN 300 220-3
Power supply 24VAC +10/-15%, 50 Hz or 60 Hz
Pollution degree 2
Software class A
Operating temperature 32°F to 122°F
(0°C to 50°C)
Storage temperature 4°F to 158°F
(-20°C to 70°C)
Radio frequency 912.0 MHz
Transmitter duty cycle <1%
Relay outputs 24VAC +10/-15%, 2.5 A maximum
Micro gap, normally open
Power connection 16" XM flexible cord connected to the Relay Module
Connection terminals 18 - 24 AWG
Antenna
Part number A3800265 Antenna (A-265) (replacement part)
IP IP20, Class III (IP: degree of inaccessibility to active parts of the
product and degree of water)
Maximum ambient RH (relative humidity) 85% at 68°F (20°C)
Power supply From Controller
Radio frequency 912.0 MHz
Transmitter duty cycle <1%
Receiver class 2
