uponor.com l 51
Chapter 13:
Technical Data
Thermostats
Part numbers A3800169 Digital Thermostat (T-169)
A3800161 Mini Sensor (T-161)
IP IP20, Class III (IP: degree of inaccessibility to active parts of the
product and degree of water)
Maximum ambient RH (relative humidity) 85% at 68°F (20°C)
ERP IV
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum
matters) tests
EN 300 220-3
Power supply 1 x CR2032 3V
Voltage 2.4 V to 3.6 V
Rated impulse voltage 0.33 kV, OVC I
Pollution degree 2
Software class A
Operating temperature 32°F to 113°F
(0°C to 45°C)
Storage temperature 14°F to 149°F
(-10°C to 65°C)
Radio frequency 912.0 MHz
Transmitter duty cycle <1%
Connection terminals 18 - 24 AWG
