54 l Smatrix Pulse | Installation and Operation Manual
Controllers
Part number A360265A Controller (X-265) with Antenna (A-265)
A360265C Controller (X-265) with Communication Module
R-208)
IP IP20, Class II (IP: degree of inaccessibility to active parts of the
product and degree of water)
Maximum ambient RH (relative humidity) 85% at 68°F (20°C)
Low voltage tests EN 60730-1* and EN 60730-2-9***
EMC (electromagnetic compatibility requirements) tests EN 60730-1 and EN 301-489-3
ERM (electromagnetic compatibility and radio spectrum
matters) tests
EN 300 220-3
Power supply 115 VAC +10/-15%, 50 Hz or 60 Hz
Internal fuse T5 F3.15AL 250 V, 5x20 3.15A quick acting
Rated impulse voltage 2.5 kV, OVC II
Pollution degree 2 2
Software class A A
Operating temperature 0°C to +45°C 32°F to 113°F
(0°C to 45°C)
Storage temperature -20°C to +70°C 4°F to 158°F
(-20°C to 70°C)
Maximum consumption 45 W
Pump and boiler relay outputs 24 VAC +10/-15%, 8 A maximum
Micro gap, normally open
General purpose input (GPI) Only dry contact
Valve outputs 24 VAC, 0.2 A average, 0.4 A peak
Power connection XM flexible cord with plug, which is connected to the controller
Connection terminals for pump, GPI, and boiler 18 - 24 AWG
Connection terminals for valve outputs 18 - 24 AWG
* EN 60730-1 Automatic electrical controls for household and similar use -- Part 1: General requirements
** EN 60730-2-1 Automatic electrical controls for household and similar use -- Part 2-1: Particular requirements for electrical controls for electrical
household appliances
*** EN 60730-2-9 Automatic electrical controls for household and similar use -- Part 2-9: Particular requirements for temperature sensing controls
