C ONTROLS AND I NDICATORS
Figure 2: Controls and Indicators
1Drive Selectors
2. Horn Button
3. Lift/Lower Button
4. Emergency Stop Button
5. Display
6. Joystick
1. Keyswitch
2. Enable Button
3. Toggle Switch (Up & Down)
4. Emergency Stop Switch
Platform Controls
Chassis Controls
1
3
4
5
6
2
1
2
34
