Upright MX19 - General Assembly

Page 6-2
Illustrated Parts Breakdown - General Assembly
MX19
General Assembly
503500-020
Item Part Description QTY.
1 503501-000 CHASSIS ASSEMBLY 1
2 065705-030 SCISSOR ASSEMBLY 1
3 503503-000 PLATFORM ASSEMBLY 1
4 503507-000 HYDRAULIC ASSEMBLY 1
5 503508-000 ELECTRICAL ASSEMBLY 1
1
2
3
