Upright MX19 - 1-7 Hydraulic Manifold Repair

Parts Location Section 3 - Service & Repair
Page 3-6 503727-002
3-4 P ARTS L OCATION
3-5
Figure 3-2: Parts Location
UPPER CONTROL BOX (UCB)
LOWER CONTROL PANEL (LCP)
DRIVE MOTORS
CHASSIS
DECK
SCISSOR STACK
LADDER
GATE
HYDRAULIC TANK
HYDRAULIC VALVE BLOCK
ECU
MOTOR CONTROLLER
PUMP MOTOR
TILT SENSOR
}
