Introduction

113100-020 - MX15 / MX19 - Operation Manual Page 3

NTRODUCTION

This manual covers the application of the MX Series Self-Propelled Work Platforms. This manual must be

stored on the machine at all times.

Read, understand and follow all safety rules and operating instructions before attempting to operate the

machine.

ENERAL

ESCRIPTION

WARNING

DO NOT use the maintenance platform without guardrails properly assembled and in place.

Figure 1:

MX Series

1. Platform Controls

2. Manual Case

3. Deck Extension

4. Platform

5. Elevating

Assembly

6. Chassis

7. Batteries

8. Charger Outlet

Plug

9. Chassis Controls

10. Emergency

Lowering Valve

Knob

11. Hydraulic Fluid

Reservoir

12. Lift Cylinder

13. Level Sensor

14. Depression

Mechanism

Supports

Front
