3-1

3. S

ERVICE

AND

EPAIR

3.1 INTRODUCTION

This section contains instructions for the maintenance of the SL26/30SL Work Platform. Procedures for the

operation inspection, adjustment, scheduled maintenance, and repair/removal are included.

Referring to Section 2 will aid in understanding the operation and function of the various components and

systems of the SL26/30SL work platform, and help in diagnosing and repair of the machine.

Refer to page 3.2 for recommended maintenance intervals.

Note: Unless otherwise specified, torque all fittings according to “Torque Specifications for

Fasteners”, and “Torque Specifications for Hydraulic Components” on page -16.

3.2 SPECIAL TOOLS

The following is a list of special tools which may be required to perform certain maintenance procedures on

the work platform.

• 0-600 PSI (0-41 bar) Hydraulic Pressure Gauge (p/n 014124-006)

• 0-3000 PSI (0-207) Hydraulic Pressure Gauge (p/n 014124-030)

• Inclinometer (p/n 010119-000)

• Tilt Sensor Adjustment Tool (p/n 030622-000)

• Quick Disconnect Gauge Port (p/n 063965-002)

3.3 PREVENTATIVE MAINTENANCE

The Complete inspection consists of periodic visual and operational checks, together with all necessary minor

adjustments to assure proper performance. Daily inspection will prevent abnormal wear and prolong the life of

all systems. The inspection and maintenance schedule is to be performed at regular intervals.

Inspection and maintenance shall be ONLY performed by personnel who are trained and familiar with

mechanical and electrical procedures.

The preventative maintenance table has been designed to be used primarily for machine service and

maintenance repair.

Please photocopy the following page and use this table as a checklist when inspecting the machine for

service.

WARNING

Be sure to read, understand and follow all

information in the Operation Section of this

manual before attempting to operate or perform

service on any SL26/30SL work platform.

WARNING

Before performing maintenance, familiarize

yourself with the operation of the machine.

Always block the elevating assembly whenever it

is necessary to enter the scissor assembly.
