Upright SL26 Series User Manual

3. Service and Repair
3-2
Preventative Maintenance Table Key
Table 3-1: Preventative Maintenance Check list
Interval
Daily=each shift or every day
50h/30d=every 50 hours or 30 days
250h/6m=every 250 hours or 6 months
1000h/2y=every 1000 hours or 2 years
Y=Yes/Acceptable
N=No/Not Acceptable
R=Repaired/Acceptable
Preventative Maintenance Report
Date:
Owner:
Model No:
Serial No:
Serviced By:
Service Interval:
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
Battery
System
Check electrolyte level Daily
Check specific gravity 6m
Clean exterior 6m
Check battery cable condition Daily
Clean terminals 6m
Engine Oil
Check level and condition Daily
Check for leaks Daily
Change oil filter 30d
Engine Fuel
System
Check fuel level Daily
Check for leaks Daily
Replace fuel filter 6m
Check air cleaner Daily
Engine
Coolant
Check coolant level (with engine cold) Daily
Replace coolant 3m
Hydraulic Oil
Check oil level Daily
Change filter 6m
Drain and replace oil 2y
Hydraulic
System
Check for leaks Daily
Check hose connections 30d
Check hoses for exterior wear 30d
Emergency
Hydraulic
System
Operate the emergency lowering valve and
check for serviceability
Daily
Controller Check switch operation Daily
Control Cable
Check the exterior of the cable for pinching,
binding or wear
Daily
Platform Deck
and Rails
Check fasteners for proper torque Daily
Check welds for cracks Daily
Check condition of deck Daily
Tires
Check for damage Daily
Check lug nuts (torque to 90 ft. lbs.) 30d
Hydraulic
Pump
Wipe clean 30d
Check for leaks at mating surfaces 30d
Check for hose fitting leaks Daily
Check mounting bolts for proper torque 30d
Drive Motors Check for operation and leaks Daily
Steering
System
Check hardware & fittings for proper torque 6m
Grease pivot pins 30d
Oil king pins 30d
Check steering cylinder for leaks 30d
Elevating
Assembly
Inspect for structural cracks Daily
Check pivot points for wear 30d
Check mounting pin pivot bolts for proper
torque
30d
Check linkage gear for wear. 6m
Check elevating arms for bending 6m
Grease linkage pins 30d
Grease linkage gear 30d
Chassis
Check hoses for pinch or rubbing points Daily
Check component mounting for proper
torque
6m
Check welds for cracks Daily
Lift Cylinder
Check the cylinder rod for wear 30d
Check mounting pin pivot bolts for proper
torque
30d
Check seals for leaks 30d
Inspect pivot points for wear 30d
Check fittings for proper torque 30d
Fore/Aft
Cylinder &
Side/Side
Cylinder
Check the cylinder rod for wear. 30d
Check mounting pin pivot bolts for proper
torque
30d
Check seals for leaks 30d
Inspect pivot points for wear. 30d
Check fittings for proper torque 30d
Axle Cylinder
Check the cylinder rod for wear. 30d
Check mounting pin pivot bolts for proper
torque
30d
Check seals for leaks 30d
Inspect pivot points for wear 30d
Check fittings for proper torque 30d
Entire Unit
Check for and repair collision damage Daily
Check fasteners for proper torque 3m
Check for corrosion-remove and repaint 6m
Lubricate 30d
Labels
Check for peeling, missing, or unreadable
labels & replace
Daily
Bubble Level
Check bubble level and target ring for
damage
Daily
Wheel
Bearings
Check wheel assembly for play 30d
Repack wheel bearings (replace wheel
bearings and seals at 2000 hours).
2y
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
