Operation and function
01/21 FlowTimer+ Set 31
9.1.4 Test mode
In FlowTimer+ test mode and in conjunction with these
operating and test instructions, the user is enabled to isolate
possible faults in the overall installation or, ideally, even to
determine the fault, even without greater prior knowledge.
The individual steps of the various tests are described under
Point 8 explained, but in general the FlowTimer+ is always put into
test mode as follows:
Briefly press the Set / Reset key (8) once.
Then press and hold the Set / Reset key (8) again (max. 10 sec.)
until the status display flashes green/yellow and the Check
display also flashes yellow.
The FlowTimer+ is now in test operation.
To return to normal operation after the test, briefly press the Set
/ Reset key (8) once.
The FlowTimer+ status indicator lights up solid green.
