Operation and function
01/21 FlowTimer+ Set 35
9.2 Status display (illuminated device edge)
No leak has been detected so far.
This display is independent of the set max. flow duration
or sensitivity!
The overall system was not tight for several hours.
The check display (12) is also permanently yellow (for
more information, see section 10.2.2 "Status display
permanently yellow").
Yellow
(flashing)
Green
(flashing)
The test mode is currently active (for more information,
see Chapter 9.1.4 "Test mode").
The water supply was automatically interrupted by
FlowTimer+.
Permanent water withdrawal or leakage that has
exceeded the preset maximum flow duration (30 min. ex
works) and the tolerance limit (sensitivity) has been
detected.
The alarm display (13) is permanently red (for more
information, see section 10.2.1 "Permanent red status
display").
