5. Function Description
5.1. User configuration process
After Convert Server start up, based on user pre-set parameters, automatically connect to wireless networks
and servers, and enter the working mode is set to open in accordance with the default serial port parameters.
The parameters which need to configure include:
 Wireless Network Parameters
 Wireless Network Name（SSID）
 Security Mode
 Encryption Key
 TCP/UDP Linking Parameters
 Protocol Type
 Link Type（Server or Client）
 Target Port ID Number
 Target Port IP Address
 Serial Port Parameters
 Baud Rate
 Data Bit
 Parity (Check) Bit
 Stop Bit
 Hardware Flow Control
 Work Mode Selection
 Transparent transmission/Serial command mode/GPIO mode/HTTPD Client mode
The following sections will introduce specific to each part in detail.
5.2. Working mode
5.2.1. Transparent Transmission Mode
Convert Server support serial interface transparent transmission mode. The benefit of this mode is achieves
a plug and play serial data port, and reduces user complexity furthest. In this mode, user should only
configure the necessary parameters. After power on, Convert Server can automatically connect to the default
wireless network and server.
