Names of Parts
1-3
19 Main power switch — Turn this switch on ( | ) before using this machine.
20 Main power switch cover — Open to operate the main power switch.
21 Handles for transport — Hold the four recessed portions at the right and left when
transporting this machine.
22 Network interface connector — When connecting this machine to a network, connect a
network cable to this connector.
23 USB interface connector — When connecting this machine to a computer through USB,
connect a USB cable to this connector.
24 Memory card slot — Insert an optional memory card to this slot.
22
23
24
19
20
21
21
To Next Page
