Utax P-C2660DN Service Manual

2PS/2PT
1-5-7
8. Release four hooks (hook A → B→ C).
Slide the right cover forward and then
remove it.
9. Remove the waste toner cover.
Figure 1-5-10
10. Release the hook. Slide the right lower
cover forward and then remove it.
Figure 1-5-11
Right cover
Hook B
Hooks C
Hook A
Waste toner
cover
Right lower cover
Hook

Utax P-C2660DN Specifications

General

Brand	Utax
Model	P-C2660DN
Category	Printer
Language	English
