Utax P-C2660DN Service Manual

2PS/2PT
1-4-37
(5)
Fuser fan motor
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Fuser fan motor and engine PWB (YC40)
2. Defective motor. Replace the fuser fan motor.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(6)
Container fan
motor does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Container fan motor and engine PWB (YC28)
2. Defective motor. Replace the container fan motor.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(7)
Paper feed clutch
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper feed clutch and engine PWB (YC3)
2. Defective clutch. Replace the paper feed clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(8)
MP feed clutch
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP feed clutch and engine PWB (YC3)
2. Defective clutch. Replace the MP feed clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(9)
Registration clutch
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Registration clutch and engine PWB (YC3)
2. Defective clutch. Replace the registration clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(10)
Middle clutch does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Middle clutch and engine PWB (YC3)
2. Defective clutch. Replace the middle clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(11)
MP solenoid does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP solenoid and engine PWB (YC4)
2. Defective solenoid. Replace the MP solenoid.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
