Vacon NX Service Manual

Option boards
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
107
5
SINCOS Encoder
board
NX OPT-AK VB00245CA UD01182A: OPT-
AK/-BE/-BG
Motion feedback
options
Basic I/O - module NX OPT-AL VB00471B UD00741J: I/O
Expander options
for NX
TABLE 17. Basic I/O boards NX OPT-A_
Basic I/O boards
NX OPT-A_
OPT Type Valid board ver-
sion
User’s manual
