10.2.2. NXS/P information
Vacon NXS/P-drive has a capacity to save last 30 faults codes and show them on dis-
play of control panel, if desired.
There is always a reason for the tripping of the drive and it should be solved before to
proceed in an operation and to avoid damages in equipment.
Fault codes from F50 and above are generated from the application. They are not sys-
tem software fault codes. Some fault codes for special system software or applications
do not have troubleshooting instruction. Instructions for such codes are available in
respective software manual.
10.3. Software revision information
This troubleshooting section cover drives with Vacon standard software. Instructions
in “Fault codes in NXL unit.” on page 21 covers fault codes in software versions until
"NXSV151" (11.55.6639) and "NXPV145" (12.26.7284).
Special software or application can have different features or fault codes.
10.3.1. NXL software information
Must use only Vacon blue or yellow cable with NXL drives when connected to PC.
10. 3. 1. 1. NXL00005V146
• Hardware compatible with all NXL-power boards from A-version but with two exep-
tions. Requires VB00352B, VB00353B or newer versions.
• Fault code F8_1 no longer appears in MF2, MF3 and MF4, when charging switch is
open less then 300ms.
F39 Device removed.
F40 Device unknown
F41 IGBT temperature. Calculated overload protec-
tion. Profile temperature has been observed.
F44 Device changed.
F45 Device added.
F50 Analogue input Iin<4mA.
F52 Keypad communication fault.
F53 Fieldbus fault.
F54 Slot fault.
F55 Actual value supervision.
TABLE 7.
Fault codes in NXL unit.
Fault code Subcode Explanation
To Next Page
