Vacon NX Service Manual

Service tools
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
19
3
9.4.5. Software version 1.13
Includes Windows Vista support.
9.5. Device properties service
A Program is required for programming the control unit, power unit and star adapter
unit in service cases. A Previously installed NCLoad or NCDrive is needed before the
program is operational. The Password protected file intended is only for authorized
personnel. Ask for the password from your contact in the After Market Service.
9.5.1. Version 2.0.2
The Brake chopper been added as default to the programming and there have been
changes to the drive ratings in pull-down menus.
9.5.2. Version 2.0.3
Support for newer system software versions which require ExtraData[3] = 3. This is
the default in easy mode. User-manual V1.3 included.
9.5.3. Version 2.0.4
• Updated user’s manual and program.
• Possible to rescale the window.
• Previously installed NCLoad or NCDrive required.
• Password protected file intended only for authorized service centres.
9.6. 3-PUT2
The tool traces the faults and verifies the functionality after the service. More informa-
tion on Vacon Extranet at http://www.extra.vacon.com. There is 3-PUT2 user’s man-
ual available, too.

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
