Vacon NX Service Manual

Option boards
24h on-call service phone: +358 (0)40 83 71 150
108
5
11.2.2. I/O Expander boards NX OPT-B_
TABLE 18. I/O Expander boards NX OPT-B_
I/O Expander
boards NX OPT-B_
OPT Type Valid board ver-
sion
User’s manual
Expander I/O -
6xDI/DO. Vacon
NX I/O expander
board with 6 bidi-
rectional terminals
NX OPT-B1 VB00286E UD00741J: I/O
Expander options
for NX
Vacon NX I/O
expander board
with a thermistor
inputand and
2xRO
NX OPT-B2 VB00259H UD00741J: I/O
Expander options
for NX
Vacon NX I/O
expander board
with a galvanically
isolated AI and 2
galvanically iso-
lated AO standard
signals 0(4)...20
mA
NX OPT-B4 VB00256M UD00741J: I/O
Expander options
for NX
I/O expander
board, 3xRO
NX OPT-B5 VB00260F UD00741J: I/O
Expander options
for NX
Temperature mea-
suring board with
3 PT-100 sensor
(3-wire) inputs.
Expander I/O.
3xPT-100 I/O
expander board.
5x42...240V AC/DI
NX OPT-B8 VB00290K UD00741J: I/O
Expander options
for NX
1xRO Expander I/
O, 1xRO, 5xDI
(42-240V AC)
NX OPT-B9 VB00266P UD00741J: I/O
Expander options
for NX
Absolute encoder
board (EnDat. SSI,
Hiperface
NX OPT-BB VB00292K UD00741J: I/O
Expander options
for NX
Resolver board 1.
Resolver board I/O
Expander
NX OPT-BC VB00339F UD01039C:
Resolver option
Expander board
3xPT1000
NX OPT-BD VB00378B UD00741K:
options for NX
