Vacon NX Service Manual

Option boards
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
111
5
11.2.4. Adapter boards NX OPT-D_
TABLE 20. Adapter boards NX OPT-D_
Adapter boards NX
OPT-D_
OPT Type Valid board ver-
sion
User’s manual
SystemBus
adapter (2xfibre
optic pairs) NXP
NX OPT-D1 VB00264H UD00741J: I/O
Expander options
for NX
SystemBus
adapter (1xfibre
optic pair) & CAN-
BUS adapter (gal-
vanically
decoupled) NXP
NX OPT-D2 VB00276F UD00741J: I/O
Expander options
for NX
RS-232 adapter
board (galvanically
decoupled),
mainly used in
application engi-
neering to con-
nect keypad
NX OPT-D3 VB00261G UD00741J: I/O
Expander options
for NX
CANBUS adapter
(galvanically
decoupled) NXP
NX OPT-D6 VB00338E UD00741J: I/O
Expander options
for NX
Line voltage mea-
surement board
NXP
NX OPT-D7 VB00379F UD01056A: OPT-
D7, Line voltage
measurement
option
