Vacon NX Service Manual

Procedures after repair
email: service@vacon.com Tel: +358 (0)201 212 575 Fax: +358 (0)204 335 091
113
6
12.3. Load test with motor
Before proceedings to test, check all of the parts, wiring and motor connections visu-
ally, to see that they are correct.
Connect the main cables, the motor cables and the earth connections.
Switch on the AC supply.
Select an application and set the correct parameters (e.g. motor). Do not set a too
high value for the current limit P2.1.5, a too short time for acceleration time P2.1.3 or
a too short time for deceleration time P2.1.4.
Run the motor without a load between the minimum and maximum frequency, and
measure the output current with a current clamp. Compare the current clamp values
to unit's monitoring value V1.4.
Load the motor to the nominal value, if possible, and compare the current clamp value
to unit's monitoring value V1.4.
Check that the fan operates normally and follow the unit temperature from the moni-
toring page V1.9.

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
