Vacon NX Service Manual

Option boards
24h on-call service phone: +358 (0)40 83 71 150
106
5
11.2.1. Basic I/O boards NX OPT-A_
TABLE 17. Basic I/O boards NX OPT-A_
Basic I/O boards
NX OPT-A_
OPT Type Valid board ver-
sion
User’s manual
Basic I/O - 6xDI,
1xDO, 2xAI, 1xAO,
+10V ref, +24V
ext.
NX OPT-A1 VB00253L UD00741J: I/O
Expander options
for NX
Basic I/O - 2xRO NX OPT-A2 VB00273G UD00741J: I/O
Expander options
for NX
Basic I/O - 2xRO,
1xThermistor
NX OPT-A3 VB00274H UD00741J: I/O
Expander options
for NX
Basic I/O -
Encoder, RS422,
NXP
NX OPT-A4 VB00268H to NXP
only!
UD00741J: I/O
Expander options
for NX
Basic I/O - Wide
range encoder, 5-
24V, NXP
NX OPT-A5 VB00267J UD00741J: I/O
Expander options
for NX
Basic I/O - DER
(Double Encoder
with Repater)
NX OPT-A7 VB00297H UD00741J: I/O
Expander options
for NX
Basic I/O - 6xDI,
1xDO, 2xAI, 1xAO,
+10V ref, +24V
ext. (isolated)
NX OPT-A8 VB00280L UD00741J: I/O
Expander options
for NX
Basic I/O - 6xDI,
1xDO, 2xAI, 1xAO,
+10V ref, +24V
ext.
NX OPT-A9 VB00283G UD00741J: I/O
Expander options
for NX
Basic I/O - 3xDI,
1xDO, 1xRO, to
NXL only!
NX OPT-AA VB00295F UD00791N: NXL
User’s manual
Basic I/O -
Encoder 15V/24V,
divider and dirc-
tion outputs
NX OPT-AE VB00367E UD00741J: I/O
Expander options
for NX
Safe disable and
atex option board
NX OPT-AF VB00328H UD01066E: OPT-
AF, Safe disable
and atex options
Expander I/O -
3xDI, 1xRO, Ther-
mistor +24V ext.
to NXL only!
NX OPT-AI VB00337D UD00791N: NXL
User’s manual

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
