SSI and Endat
encoders
NX OPT-BE VB00244CA UD01182A: OPT-
AK/-BE/-BG
Motion feedback
options
Resolver board 2 NX OPT-BG VB00433A UD01182B: OPT-
AK/-BE/-BG
Motion feedback
options
TABLE 18. I/O Expander boards NX OPT-B_
I/O Expander
boards NX OPT-B_
OPT Type Valid board ver-
sion
User’s manual

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
